12 Channel 7 Inch Touch Screen ECG Machine Electrocardiograph Standard 12 Lead

    Buy cheap 12 Channel 7 Inch Touch Screen ECG Machine Electrocardiograph Standard 12 Lead from wholesalers

    Buy cheap 12 Channel 7 Inch Touch Screen ECG Machine Electrocardiograph Standard 12 Lead from wholesalers
    • Buy cheap 12 Channel 7 Inch Touch Screen ECG Machine Electrocardiograph Standard 12 Lead from wholesalers
    • Buy cheap 12 Channel 7 Inch Touch Screen ECG Machine Electrocardiograph Standard 12 Lead from wholesalers
    • Buy cheap 12 Channel 7 Inch Touch Screen ECG Machine Electrocardiograph Standard 12 Lead from wholesalers

    12 Channel 7 Inch Touch Screen ECG Machine Electrocardiograph Standard 12 Lead

    Ask Lasest Price
    Brand Name : DY-MED
    Model Number : ECG-12A
    Certification : ISO13485&CE
    Price : $180-$500/pcs
    Payment Terms : T/T, Western Union
    Supply Ability : 2000Units per month
    Delivery Time : 3-7working days
    • Product Details
    • Company Profile

    12 Channel 7 Inch Touch Screen ECG Machine Electrocardiograph Standard 12 Lead

    12 Channel 7 inch Touch Screen ECG Machine Electrocardiograph Standard 12 Lead

    Feature
    7 inch high resolution color touch screen
    12-lead simultaneous acquisition and display
    ECG Automatic measurement and interpretation function
    Complete digital filters, resisting baseline drift, AC and EMG interference
    Compact and lightweight design
    Support USB flash disk and micro memory card to extend memory
    Software upgrade via USB/memory card
    Built-in rechargeable Li-ion battery
    Specification
    Items
    specification
    Features
    7 "display,touch screen
    Support Ecg analysis capabilities
    Lead
    standard 12 leads
    lead acquisition
    synchronously 12 leads
    Input circuit
    Floating; Protection circuit against Defibrillator effect
    Input Impedance
    ≥50MΩ
    Input circuit current
    ≤0.0.05μA
    Record mode
    Automatic: 3CH×4+1R, 3CH×4, 3CHx2+2CHx3,3CHx2+2CHx3+1R,6CHX2;
    Manual: 3CH, 2CH, 3CH+1R, 2CH+1R;
    Rhythm: Any lead selectable.
    Filter
    EMG Filter: 25 Hz / 30 Hz / 40Hz/75 Hz / 100 Hz / 150Hz
    DFT Filter: 0.05 Hz/ 0.15 Hz
    AC Filter: 50 Hz / 60Hz
    CMRR
    >100dB
    Patient current leakage
    <10μA
    Input Circuit Current
    <0.05µA
    Frequency Response
    0.05Hz~150Hz (-3dB)
    Sensitivity
    2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV
    Anti-baseline Drift
    Automatic
    Time constant
    ≥3.2s
    Noise level
    <15μVp-p
    Paper speed
    12.5 mm/s, 25 mm/s, 50 mm/s
    Recording mode
    Thermal printing system
    Paper specification
    80mmx20m paper roll

    12 Channel 7 Inch Touch Screen ECG Machine Electrocardiograph Standard 12 Lead12 Channel 7 Inch Touch Screen ECG Machine Electrocardiograph Standard 12 Lead12 Channel 7 Inch Touch Screen ECG Machine Electrocardiograph Standard 12 Lead
